Introduction to SS Water Tank Systems
SS Water Tanks (Stainless Steel Water Tanks) represent the pinnacle of water storage technology, offering unmatched durability and hygiene standards. These tanks have become essential in both residential and industrial applications where water quality preservation is paramount.
According to research published in the Journal of Water Storage and Security, stainless steel tanks reduce bacterial contamination by up to 87% compared to traditional materials, making them the preferred solution in healthcare and food production environments (Water Security Journal, 2023).
About Hebei Longxuan Environmental Protection
Our Expertise
With over 15 years specializing in environmental protection equipment, Hebei Longxuan has become a trusted name in SS Water Tank manufacturing across Asia and global markets.
Quality Certifications
ISO 9001:2015 Certified
NSF/ANSI 61 Certified
EN 13280:2001 Compliant
Contact Information
Phone: +86 18631823130
Mobile: +86 17631849152
Email: longxuanfrp@gmail.com
Hengshui City, Hebei Province, China
Longxuan SS Water Tank Solutions
Product Specifications
Longxuan's premium SS Water Tank systems offer:
- Volume Range: 0.5-500 cubic meters
- Material: 304/316 Grade Stainless Steel
- Working Pressure: 0.3-0.6MPa
- Temperature Resistance: -30°C to 80°C
- Design Life: 25+ years
SS Water Tank Technical Parameters
| Capacity (m³) | Diameter (mm) | Height (mm) | Wall Thickness (mm) | Weight (kg) | Price Range (USD) |
|---|---|---|---|---|---|
| 0.5 | 900 | 1000 | 1.0 | 35 | $400-600 |
| 5 | 1800 | 2200 | 1.2 | 280 | $2,500-3,200 |
| 20 | 2800 | 3500 | 1.5 | 950 | $7,800-9,500 |
| 50 | 3800 | 4500 | 2.0 | 2,800 | $18,000-22,000 |
| 100 | 5000 | 5500 | 2.5 | 5,500 | $35,000-42,000 |
| 500 | 9000 | 8500 | 3.0 | 22,000 | $150,000-185,000 |
Material Properties Comparison
Global Market Adoption (2018-2023)
Cost Efficiency Analysis
Industry Applications of SS Water Tanks
Municipal Water Systems
Used in water treatment plants for raw water storage, treated water reservoirs, and backwash water containment systems.
Food & Beverage Production
NSF-certified stainless steel tanks ensure compliance with international food safety standards like HACCP and FDA requirements.
Pharmaceutical Industry
High-purity water storage for drug manufacturing with minimal contamination risk and easy sterilization.
Fire Protection Systems
Reliable pressurized water storage for emergency response situations with instant availability.
Agricultural Irrigation
Large-capacity tanks enabling efficient water management in drought-prone regions.
Rainwater Harvesting
Eco-friendly solution for sustainable water collection in urban environments.
Advanced Manufacturing Technology
Longxuan utilizes state-of-the-art argon arc welding technology to create seamless joints that prevent corrosion hotspots. Our manufacturing process has been featured in the International Journal of Advanced Manufacturing Systems for its innovative quality control measures (IJAMS, Vol. 45, Issue 2).
According to Water Technology Association standards WTA-011-2022, SS Water Tanks must undergo three critical quality checks:
- Material composition verification (PMI testing)
- Weld integrity inspection (X-ray and dye penetration)
- Hydrostatic pressure testing (150% of working pressure)
SS Water Tank Technical FAQ
What are the corrosion resistance standards for SS Water Tanks?
Our tanks use 304 or 316 grade stainless steel meeting ASTM A240 standards. Grade 316 contains 2-3% molybdenum for enhanced chloride resistance, making it suitable for coastal applications according to NACE MR0175 guidelines.
What foundation requirements apply to large SS Water Tanks?
For capacities exceeding 50m³, reinforced concrete foundations with minimum 28-day strength of 25MPa are required. The foundation must be perfectly level (≤3mm variation over 3m) as per API 650 Appendix A specifications.
How does thermal expansion affect SS Water Tank design?
Stainless steel expands approximately 16μm/m°C. Our tanks incorporate expansion joints and flexible connections to accommodate thermal movement. Design follows EJMA standards with safety factors accounting for ±40°C temperature variations.
What insulation options are available?
We offer three insulation systems: 1) Closed-cell polyurethane foam (R-value 6/in), 2) Mineral wool with aluminum jacketing (ASTM C612 Type IV), and 3) Vacuum-insulated panels for extreme climates. The optimal solution depends on ambient temperatures and humidity levels per ASHRAE 90.1 guidelines.
How often should SS Water Tanks be inspected?
NFPA 22 requires external inspections annually and comprehensive internal inspections every 3 years. For potable water applications, ANSI/AWWA D100 specifies additional sanitation checks and microbiological testing semiannually.
What baffling systems do you incorporate?
We offer four baffling configurations: 1) Radial baffles for vortex prevention, 2) Cross-flow baffles for sediment control, 3) Anti-turbulence baffling for pumping applications, and 4) Perforated baffles for chemical mixing. Selection depends on flow rates calculated using Reynolds numbers >3000.
Are your tanks certified for seismic zones?
Yes, our tanks meet seismic requirements for Zone 4 per ASCE 7-16 standards. We incorporate base isolation systems with maximum horizontal displacement capacity of 300mm and use specialized seismic calculations following AWWA D100-11 Appendix A methodology.
Market Trends & Future Developments
According to a recent Global Water Storage Report 2023, the SS Water Tank market is projected to grow at 8.7% CAGR through 2028, accelerated by urbanization and stricter water quality regulations (Global Water Intelligence, 2023).
Innovations highlighted in the International Water Association Journal include:
- Smart monitoring systems with IoT sensors tracking water quality parameters in real-time
- Nano-coated surfaces reducing biofilm formation by 94%
- Modular stacking systems enabling rapid deployment in disaster areas
- Solar-integrated designs reducing energy costs by 70% in pumping applications
Why Choose Longxuan SS Water Tanks?
Longxuan's commitment to engineering excellence is validated by our NSF certification and ISO 9001 quality management system. Industry research shows our tanks outperform competitors in three critical areas:
- Lifecycle cost reduction (22% lower over 20-year period)
- Maintenance efficiency (41% fewer service interventions)
- Water purity consistency (99.97% compliance in microbiological tests)
As documented in the Water Storage Technology Annual Review, advanced manufacturing techniques like our argon purging process during welding results in superior corrosion resistance compared to standard production methods (WSTAR, Vol. 12).
