HDPE Water Supply And Drainage Pipe
1. Product Overview
HDPE (High-Density Polyethylene) pipes are lightweight, flexible, and corrosion-resistant plastic pipes widely used for potable water supply, drainage, irrigation, and industrial fluid transport.
Key Advantages:
✔ Corrosion-Free – Resistant to chemicals, acids, and alkalis
✔ Long Lifespan – 50+ years under normal conditions
✔ Leak-Free Joints – Heat-fused connections ensure perfect sealing
✔ Flexible & Durable – Withstands ground movement and pressure
✔ Cost-Effective – Lower installation & maintenance costs vs. metal pipes
2. Material Grades & Standards
|
Grade |
Density (g/cm³) |
Pressure Rating (PN) |
Standards |
|
PE80 |
0.941–0.965 |
PN6–PN10 |
ISO 4427, GB/T 13663 |
|
PE100 |
0.945–0.960 |
PN10–PN25 |
EN 12201, ASTM D3035 |
Certifications:
ISO 9001 (Quality Management)
NSF/ANSI 61 (Potable Water Safety)
EN 12201 / ISO 4427 (European & International Standards)
3. Technical Specifications
|
Parameter |
Specifications |
|
Diameter (DN) |
16mm – 2000mm |
|
Pressure Classes |
PN6, PN8, PN10, PN12.5, PN16, PN20, PN25 |
|
SDR (Standard Dimension Ratio) |
SDR9, SDR11, SDR13.6, SDR17, SDR21, SDR26 |
|
Color |
Black (blue stripes for potable water), White (for drainage) |
|
Operating Temp. |
-40°C to +60°C (short-term up to 80°C) |
|
Burst Pressure |
≥3× working pressure |
4. Applications
✔ Potable Water Supply (Municipal & Residential)
✔ Sewage & Drainage Systems (Gravity & Pressure)
✔ Irrigation & Agricultural Water Transport
✔ Industrial Piping (Chemical, Mining, Slurry)
✔ Gas Distribution (Yellow-striped HDPE pipes)
5. Installation Methods
(1) Butt Fusion (Most Common)
Process: Heating pipe ends and pressing them together
Advantages: Strong, leak-proof, permanent joints
(2) Electrofusion (For Fittings & Repairs)
Process: Using electrically heated couplers
Advantages: Ideal for confined spaces
(3) Mechanical Joints (Flanges, Compression Fittings)
Process: Rubber-sealed connections
Advantages: No welding required, easy disassembly
6. Comparison with Alternative Pipes
|
Feature |
HDPE |
PVC |
Ductile Iron |
Steel |
|
Corrosion Resistance |
★★★★★ |
★★★★☆ |
★★★☆ |
★★☆ |
|
Flexibility |
★★★★★ |
★★★☆ |
★★☆ |
★☆☆ |
|
Lifespan |
50+ yrs |
25-50 yrs |
30-50 yrs |
15-30 yrs |
|
Installation Cost |
Low |
Very Low |
High |
Very High |
|
Leak Risk |
None (fusion joints) |
Medium (glued joints) |
High (bolted joints) |
High (welded joints) |
7. Quality Control & Testing
Hydrostatic Pressure Test (ISO 1167)
Tensile Strength Test (ISO 6259)
Impact Resistance Test (ASTM D2444)
Oxidation Induction Time (OIT) (ASTM D3895)
8. Packaging & Delivery
Standard Lengths: 6m, 12m (or coiled for small diameters)
Protection: Plastic end caps + UV-resistant wrapping
MOQ: 1 ton (custom orders accepted)
Lead Time: 7-15 days (stock available for common sizes)
9.Why Choose Our HDPE Pipes?
✅ 100% Virgin Material – No recycled content for maximum durability
✅ Full Certification – NSF, ISO, CE, and SGS reports available
✅ Custom Fabrication – Cutting, threading, and fusion services
✅ Technical Support – Free installation guidance & project consulting
Contact us for quotes, material samples, or technical data sheets (TDS)!
